PLANET preklopnik (Switch) 5-port 10/100Base-TX

Key Features
– Comply with IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX
– 5-port 10/100Mbps Auto-Negotiation ports – 10/20Mbps, 100/200Mbps Auto-sensing
– Compact size design for wall mount or desktop placement
– High performance Store-and-Forward Switching Architecture
– Runt and CRC filtering
– Flow control (Back Pressure) supports in half-duplex mode
– 1K MAC Address Table, automatically learning and aging
– LED indicators array for easy diagnostic, troubleshooting
– Plug-and-Play Installation
– Auto-MDI/MDIX on each port

Hardware Specification
– Network Connector: 5-port RJ-45 for 10/100Base-TX
– Switch Throughput: 0.74Mpps
– Switch Fabric: 1Gbps
– MAC Address: 1K MAC address table with Auto learning function
– Shared Buffer: 384K
– Power Requirement: 9V DC, 700mA
– Operating Environment: 0 – 50 Degree C, 5% – 95% RH
– Storage Environment: -20 – 70 Degree C, 5% – 95% RH
– Dimension (W×D×H ): 184×110×30 mm
Switch Specification
– Switch Architecture: Store-and-Forward
– Flow Control: IEEE 802.3x full duplex operating and flow control
Standard Compliance
– Network Standard:
* IEEE 802.3 10Base-T
* IEEE 802.3u 100Base-TX
* IEEE 802.3x Flow Control and Back pressure
– EMI: FCC Class B, CE
